Features:

• Pneumatic break system
• Pneumatic lifting system, easy to lift the tire
• 16 sets adaptor ,specialise for different size tire
• Self calibrating and self diagnosis program
• For standard and special rim balancing
• Display unblancing data accurately, indicate the balancing weight putting position.
• Accuracy shaft
• High quality accessories incuding lock nut, pliers, ruler, etc.

Technical data:

• Max wheel weight:  200 kg
• Motor power: 0.5 kW
• Power supply:  220V/50Hz, Single Phase
• Balancing speed: 200 rpm
• Balancing precision:  +5 g
• Rim diameter:  10’’-26’’/253-660mm
• Rim width:  1.5’’-20’’/38-508mm
• Cycle time:  10 s
• Noise: <70 dB
• Gross weight: 280 kg
• Packing size (H*L*W):   1230*1250*1040mm
• Volume: 1.6 m³
